SMT100M-C6
- Drive system
- Working device
- Control system
- Traveling system
- Easy maintenances
-
Drive system
● SDEC electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts universality, and low maintenance cost.
● The energy-saving technologies, including automatic idling of engine, are utilized to realize better fuel economy, low emission load, and high working efficiency for the whole machine.
● The milling drum is driven by mechanical belt and the drive belt is hydraulically tensioned, featuring high drive efficiency, effectively mitigated operating impact, and stable and reliable power transmission.
-
Working device
● The optimized cutter arrangement and excellent manufacturing accuracy guarantee low operating vibration of machine.
-
Control system
● The standard controller and display feature high intelligence level and convenient human-machine interactions.
-
Traveling system
● The standard air source can realize the pneumatic cutter change and air filter cleaning.
● The large hood with backward-opening design easies the maintenances.
-
Easy maintenances
● The standard air source can realize the pneumatic cutter change and air filter cleaning.
● The large hood with backward-opening design easies the maintenances.
| Parameter name | SM50T-3 (Standard version) |
| Performance parameters | |
| Operating weight (Kg) | 6600 |
| Transport weight(Kg) | 6280 |
| Maximum milling width (mm) | 500 |
| Maximum milling depth (mm) | 180 |
| Engine | |
| Engine model | WP4.1 |
| Rated power/rated speed (kW/rpm) | 103/2300 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 3105*2075*2340 |
| Driving performance | |
| Traveling speed (km/h) | 0-8 |
| Working speed (m/min) | 0-50 |
| Conveyor System | |
| Width of conveyor belt (mm) | – |
| Swing angle of conveyer (Rightward/leftward) (°) | – |
| Tank capacity | |
| Fuel tank (L) | 180 |
| Working device | |
| Number of milling cutters (Piece) | 54 |
